Weathering Aging testing machine

UV Weathering Test Chamber
  • Short Description
    The UV Weathering Test Machine stands as the most globally trusted, universally adopted accelerated weathering tester, proving indispensable in more laboratories around the world than any other model. Renowned across diverse industries, our UV Test Chamber is pivotal in fields such as printing ink, paint, plastics, print, packaging, automotive, metal, electronics, and medical, ensuring quality and durability.
    UV Weathering Test Machine ,Our Advanced UV Test Chamber masterfully replicates the destructive weathering effects of prolonged outdoor exposure on materials and coatings. It subjects samples to the harshest weathering elements: ultraviolet radiation, moisture, and heat. Utilizing fluorescent lamps, it emits a UV radiation spectrum to mimic natural sunlight. Through forced condensation, it delivers consistent moisture levels, while integrated heaters precisely manage temperature for optimal testing conditions.
  • SEND INQUIRY NOW
Product Details

Product description

The UV Weathering Test Machine stands as the most globally trusted, universally adopted accelerated weathering tester, proving indispensable in more laboratories around the world than any other model. Renowned across diverse industries, our UV Test Chamber is pivotal in fields such as printing ink, paint, plastics, print, packaging, automotive, metal, electronics, and medical, ensuring quality and durability.

UV Weathering Test Machine ,Our Advanced UV Test Chamber masterfully replicates the destructive weathering effects of prolonged outdoor exposure on materials and coatings. It subjects samples to the harshest weathering elements: ultraviolet radiation, moisture, and heat. Utilizing fluorescent lamps, it emits a UV radiation spectrum to mimic natural sunlight. Through forced condensation, it delivers consistent moisture levels, while integrated heaters precisely manage temperature for optimal testing conditions.


Technical Parameters

1. Temperature range: RT room temperature ~ +70ºC
2. Humidity range: >=90%RH
3. Temperature uniformity: <=±2ºC
4. Temperature fluctuation: ±0.5ºC
5. Lamp center distance: 70mm
6. Distance between the test product and the center of the lamp: 50mm
7.Irradiance: adjustable within 0.1 ~ 0.89W/m2
8. The test period of light, condensation and spray can be adjusted
9. Lamp: UVA340 lamp, L=1200/40W (import), 8 (UVA service life more than 1600h)
10. Controller: Color touch screen China Taiwan (Willuntong) intelligent controller
11. Temperature control mode: PID self-tuning SSR control
12.Water depth: 25mm automatic control
13.Effective irradiation area: 900×450mm
14.Ultraviolet wavelength: UVA range is 315 ~ 400nm
15.Test time: 0 ~ 9999H(adjustable)
16.Irradiation blackboard temperature: +50ºC ~ +70ºC
17.Unit functions: light, condensation, rain
18.Internal dimensions: W1100*D500*H500 (mm)
19.External dimensions (approx) : W1350*D650*H1550 (mm)
20.Case material:
a. Outer box material: Baosteel high-quality steel plate electrostatic spray treatment;
b. Inner box material: 1.2mm thick SUS304# heat-resistant and cold-resistant stainless steel plate.
c. The box is made of CNC equipment, advanced technology, smooth lines, beautiful and generous
d. The air duct in the box adopts a single circulation system, and has an imported axial flow fan, which improves the flow brightness and heating ability of the air
The amplitude improves the temperature uniformity in the test chamber.
e. The heating method is the inner tank type heating, fast heating and uniform temperature distribution.
f. The lid is bidirectional clamshell type, easy to close.
g. The water level of the inner tank is automatically replenishing, preventing the heating tube from being damaged by air burning. h. The sample holder is made of stainless steel or aluminum alloy
i. The bottom of the unit is fixed with high-quality PU movable wheels
j. The drainage system uses U-shaped sedimentation device to drain
k. The surface of the test sample is parallel to the plane of the UV lamp. The spray system is equipped with automatic sprinkler heads and adjustable water pressure
21.System noise: ≤68dB (500mm from the surface of the equipment and operating bit, respectively)
22.Cooling method: water-cooled (customers provide frozen water
23.Inlet flow rate: ≤2m³/H
24.Water inlet temperature: 5-32ºC
25.Inlet pressure: 0.2MPa
26.Environment heat dissipation: ≤0.3KW
27.Equipment fault protection: overheat protection circuit breaker, humidification system overheat protection, compressor overload protection, control system overload protection
Protection, overload indicator light, phase sequence protection, water shortage protection, high pressure and low pressure protection, over temperature protection, water supply delay protection, fan overcurrent protection.


Equipment Characteristics

1. Enhanced simulation of sunlight's ultraviolet spectrum, delivering superior accuracy.
2. State-of-the-art irradiance closed-loop control system for continuous monitoring and swift calibration.
3. Accurately mimics natural condensation to replicate real-world wet conditions.
4. Features the UV340 lamp known for its excellent correlation to natural weathering.
5. Ensures spectrum stability and boasts a remarkable lamp life of 1600 hours.
6. Designed for minimal upkeep and cost-effective operation.
