Product description
Xenon arc lamps that simulate the full spectrum of sunlight can reproduce the destructive light waves existing in different environments, providing corresponding environmental simulation and accelerated tests for scientific research, product development and quality control.
The light resistance and weather resistance of certain materials under the action of high-temperature light sources are evaluated by conducting aging tests on material samples exposed to the light and thermal radiation of xenon arc lamps. It is mainly used in the automotive, coating, rubber, plastic, pigment, adhesive, fabric, aerospace, shipbuilding, electronics industry, packaging industry, etc.
This xenon lamp weathering test chamber can be used for the selection of new materials, the alteration of existing materials or the assessment of durability changes after the composition of materials changes. It can well simulate the changes that materials undergo when exposed to sunlight under different environmental conditions.
Conform to the standard
GB/T16422.3, 15422.1 AATCCM16, ASTM-D4459, GBT2423.24
Detailed parameters
Product Features
Adopt optical fiber transmission
Measure the radiation intensity of xenon lamps to avoid the problem of measurement value errors caused by temperature reasons.
Sample holder
The blackboard thermometer BPT or the black standard thermometer BST has been installed.
Record
For each test working time, the equipment is equipped with a timer on the operation panel, which can control the equipment time. When the timer ends, the equipment will automatically shut down.
Protective device
A protective facility that ensures the xenon arc lamp can operate normally and is not easily damaged. When the door is opened, the xenon lamp automatically extinguishes and the entire machine stops working.
Xenon lamp tube
Vertically installed at the center of the box, a drum-type sample rack is installed around the lamp tube. There are several standard-sized fixtures on the sample rack.
Equipment operation
The sample holder rotates around the lamp tube to ensure irradiation uniformity at each Angle. Therefore, the water-cooled xenon lamp aging test chamber is suitable for thin sheet-like or slicing samples
Product structure
It is composed of a test chamber, a heating/lighting system and electrical control
