Table tennis testing machine

Ping-pong table rebound height and ping-pong ball bounce (light-controlled type) test machine
  • Short Description
    Table tennis rebound height test, meet or exceed the requirements of GB/T 20045-2005, GB/T32597-2016, GB/T 19851.7-2005, GB/T 19851.8-2005, QB/T2700-2005 standards.
  • SEND INQUIRY NOW
Product Details

Product description

Table tennis rebound height test, meet or exceed the requirements of GB/T 20045-2005, GB/T32597-2016, GB/T 19851.7-2005, GB/T 19851.8-2005, QB/T2700-2005 standards.


Technical data
Spring steel plate: thickness ≥8.0mm, the material is 45 steel, the level should be adjusted. The sample to be measured is fixed through the rubber suction head, and the distance between the bottom of the sample ball to be measured and the round steel plate is 305mm, which is adjustable.
Sensor height 50mm±1mm, adjustable.
The measured sample fell in free fall to the round steel plate after the second fall, the photocell was covered twice, and the bounce height was calculated by the microcomputer and displayed on the digital tube. The display data accuracy was 0.1mm.


Technical parameters

1. Control mode: PLC+HMI
2. Test height: 305mm±1mm
3. Photoelectric sensor: infrared sensor
4. Sensor height: 50±1mm
5. The rest meet the requirements of the relevant items in the GB/T 20045-2005 standard.
6. 40mm excellent ping-pong balls can be used to test the rebound height of the table tennis table, meeting the requirements of the relevant items in GB/T 32597-2016 standard.
